Construction Packages

creativezone construction Packages
Basic Package
Rs. 2199/sqft
Design & Drawings
  • .2D Floor Plan: Included
  • .Schedule of Openings: Included
  • Working Drawings: Included
  • .Electrical and Plumbing Drawings: Included
Flooring & Tiles
  • .Living & Dining: Vitrified tiles of choice up to Rs.55 per sqft
  • .Kitchen, Bedrooms & Other Common Areas: Vitrified tiles of choice up to Rs.55 per sqft
  • Staircase: Granite of up to Rs.70/- per sqft
  • .Balcony, Setback (if charged) & Parking: Antiskid Tiles of up to Rs.55/- per sqft
  • .Bathroom Walls: Tiles of up to Rs.55/- per sqft up to 8 feet height
  • .Bathroom Floor: Antiskid Tiles of up to Rs.55/- per sqft
  • .Kitchen Dado: 2 feet height above countertop – Rs.55/- per sqft
  • .Kitchen Counter Slab: Granite choice of Rs.90/- per sqft
  • .Epoxy Grouting: Not Available
  • .Terrace Cooling Tiles: Not Available
Waterproofing
  • Waterproofing shall be done in the terrace slab, all washrooms, and balconies using Fosroc / Dr Fixit Brush bond or equivalent brands.
Fittings
  • .Kitchen Sink with Accessories: ISI Mark Products up to Rs.2,500/-
  • .Kitchen Sink Faucet: ISI Mark Products up to Rs.900/-
  • .CP & Sanitary Fittings: ISI Mark Products up to Rs.15,000/- per toilet, for powder room - Not Available
  • .Utility Sink & Accessories: Included
Civil Construction
  • .Floor Height: 11' from finished floor level to finished floor level
  • .Steel: Client Choice
  • .Cement: JSW or Penna
  • .Concrete: Constructed with M-20 grade concrete
  • .Aggregates: 20mm & 40mm
  • .Foundation: Assumed to be isolated footings in regular soil with a bearing capacity of 180kN/m² and above, up to a depth of 5 feet. Additional charges apply for specialized foundation designs or additional excavation depth beyond 5 feet.
  • .Plastering: Internal plastering (1:5 cement mortar), external plastering (1:5 cement mortar), and ceiling plastering (1:4 cement mortar). Internal plaster thickness 15mm, external plaster 12mm + 8mm, applied in two coats.
  • .Anti-termite Treatment: Adheres to standard procedures
  • .Chicken Mesh: Used at beam, column, and masonry wall junctions, and at electrical conduit chases.
  • .Plinth Level: Set at 1 foot 6 inches above the existing ground level.
  • .Blockwork Masonry: Standard solid concrete blocks with plaster, 4' for internal partitions and 6' for external walls.
  • .Sand: Double washed M-sand for masonry and P-sand for plastering.
  • .Lintels: Provided only over openings with a bearing of 6? into the edge of the openings.
  • .UG Sump: Constructed with 6? concrete blocks, waterproof plastered, with a capacity of 6,000 liters.
  • .Entry Ramp: Not Available
  • .Protection: Protection of neighboring houses with tarpaulin.
  • .Gas Provision: Not Included
  • .Sill Level Band: Included to prevent future cracks.
  • .Damp Proof Course: Included to prevent dampness.
  • .Parapet Wall: 3' height
Electricals
  • .Switches & Switch Boards: Hi Fi or equivalent
  • .UPS Provision: Included
  • .CCTV: Not Available
  • .Electrical Points: Light and power points provided as per design
  • .Geyser Points: Provided in all bathrooms
  • .AC Provision: Not Available
  • .Conduits: High-quality, concealed in slabs and walls
  • .Fire-Proof Copper Wire: Finolex or Polycab
  • .External Electrification: Included
  • .Main DB & MCB: ABB, IndoAsian, Siemens, or equivalent make
  • .Electric Car Charging Point: Not Available
  • .Home Automation: Not Available
  • .Electrical & Plumbing budget: Rs.300/sqft on buildup area.
Plumbing
  • .CPVC & PVC Pipes: Ashirvad, Astral, or equivalent brands
  • .Overhead Tank (OHT): 1,000 liters, Ganga or equivalent
  • .Water Supply System: Internal and external
  • .External Sewage System: Includes inspection chambers and sewage outlet to site boundary
  • .Solar & Geyser Provision: Provided for all toilets
  • .Rainwater Harvesting Facility: Not Available
  • .Plumbing: CI chamber covers provided for inspection chambers
  • .Separate Sewage & Drainage Lines: Installed
  • .Hot and Cold-Water Inlet: Not Available
Fabrications
  • .MS Gate: Up to Rs.900 per running foot
  • .External Staircase & Balcony Railing: MS Railing up to Rs.350 per running foot
  • .Internal Staircase: MS Railing up to Rs.550 per running foot (If applicable)
Doors & Windows
  • .Percentage of Openings: Maximum 8.5% of built-up area for windows and balcony doors
  • .Main Door: Teak wood frame and shutter including hardware – Rs.45,000 per door for owner house, frame thickness of 6 inches by 4 inches, shutter thickness of 38mm. For other houses, main door fitting budget will be Rs.5,000/- per door (if applicable).
  • .Internal Door: Sal wood frame and flush shutter including hardware – Rs.15,000 per door. Frame thickness of 5 inches by 3 inches, shutter thickness of 32mm.
  • .Puja Door: Not Included
  • .Polish: Not Available
  • .Bathroom Door: Frame and shutter including hardware – Rs.5,000 per door. Frame thickness of 4 inches by 2 inches, shutter thickness of 32mm.
  • .UP-play/PVC/Wooden Windows: Aluminium - 5mm clear glass with MS grills. Basic price: Rs.400 per sqft with MS grill.
Painting
  • .Internal Wall & Ceiling: 2 coat wall putty + 1 coat primer + 2 coat Tractor Emulsion – Nippon brand
  • .External Walls: 1 coat primer + ACE weatherproof paint Nippon brand
Compound Wall (If Charged)
  • .Solid Block Walls: 3 inches thick, designed to complement the elevation.
  • .Construction Details: Readymade or precast - includes excavation, foundation, PCC, size stone masonry with DPC course above SSM.
  • .Height of Compound Wall: 3 feet from plinth level.
  • .Finish: Compound wall will be plastered and painted.
Elevation
  • .Aesthetic Design: Includes an aesthetically pleasing elevation design.
  • .Design Options: One 3D elevation design is provided for the client to further refine.
Structural Warranty
  • .Construction Guarantee: 2 years
  • .Structural & Waterproofing Warranty: 8 years
Terms & Conditions
  • .Cost: Includes all applicable taxes.
  • .Floor Plan: Must be finalized within 30 days from the date of releasing the first floor plan proposal by the architect.
  • .SSM: Below the plinth is not included; if required, it will be charged based on actual costs.
  • .Sewer Line Connections: Included up to 10 feet from the building.
  • .Steel & Cement Budget: Steel brand chosen by the client, with a budget of 50,000 per MT & cement with a basic price of Rs.350 per bag. Any cost difference at the time of purchase will be charged after consulting with the client.
  • .Water, Electricity & Miscellaneous: Client must provide water and electricity for the work. Rates are based on natural earth excavation. Additional charges apply for concrete structures, stones, rock slush, or any other obstacles encountered during excavation.
  • .Site and Road Level: Cost assumes that the site and road are at the same level.
  • .Fixtures & Equipment: Does not include equipment, machinery, or fixtures such as sump pumps, solar panels, geysers, or bulbs.
  • .Approval for Power and Water: Client will bear the approval costs for power and water. Road cutting charges for connecting electricity and sewage lines are not included and will be charged additionally.
  • .Backfilling Soil: Costs for purchasing new earth or removing existing earth for excavation/backfilling purposes will be charged based on actual costs.
  • .Liaison: Assistance with BBMP/BDA/BMRDA and similar authorities will be provided by the company, with fees to be borne by the client.
standard Package
Rs. 2499/sqft
Design & Drawings
  • .2D Floor Plan: Included
  • .3D Elevation: Included
  • .Soil test & Structural Drawings: Included
  • .Schedule of Openings: Included
  • .Furniture Layouts: Included
  • .Working Drawings: Included
  • .Electrical and Plumbing Drawings: Included
  • .Isometric Views: Not Available
Flooring & Tiles
  • .Living & Dining: Vitrified tiles of choice up to Rs.80 per sqft
  • .Kitchen, Bedrooms & Other Common Areas: Vitrified tiles of choice up to Rs.80 per sqft
  • .Staircase: Granite of up to Rs.90/- per sqft
  • .Balcony, Setback (if charged) & Parking: Antiskid Tiles of up to Rs.80/- per sqft
  • .Bathroom Walls: Tiles of up to Rs.80/- per sqft up to 8 feet height
  • .Bathroom Floor: Antiskid Tiles of up to Rs.80/- per sqft
  • .Kitchen Dado: 2 feet height above countertop – Rs.90/- per sqft
  • .Kitchen Counter Slab: Granite choice of Rs.110/- per sqft
  • .Epoxy Grouting: Not Available
  • .Terrace Cooling Tiles: Not Available
Waterproofing
  • .Waterproofing shall be done in the terrace slab, all washrooms, and balconies using Fosroc / Dr Fixit Brush bond or equivalent brands.
Fittings
  • .Kitchen Sink with Accessories: ISI Mark Products up to Rs.4,000/-
  • .Kitchen Sink Faucet: ISI Mark Products up to Rs.1,300/-
  • .CP & Sanitary Fittings: ISI Mark Products up to Rs.20,000/- per toilet, for powder room up to Rs.10,000/-
  • .Utility Sink & Accessories: Included
Civil Construction
  • .Floor Height: 11' from finished floor level to finished floor level
  • .Steel: Client Choice
  • .Cement: JSW or Penna
  • .Concrete: Constructed with M-20 grade concrete
  • .Aggregates: 20mm & 40mm
  • .Foundation: Assumed to be isolated footings in regular soil with a bearing capacity of 180kN/m² and above, up to a depth of 5 feet. Additional charges apply for specialized foundation designs or additional excavation depth beyond 5 feet.
  • .Plastering: Internal plastering (1:5 cement mortar), external plastering (1:5 cement mortar), and ceiling plastering (1:4 cement mortar). Internal plaster thickness 15mm, external plaster 12mm + 8mm, applied in two coats.
  • .Anti-termite Treatment: Adheres to standard procedures
  • .Chicken Mesh: Used at beam, column, and masonry wall junctions, and at electrical conduit chases.
  • .Plinth Level: Set at 1 foot 6 inches above the existing ground level.
  • .Blockwork Masonry: Standard solid concrete blocks with plaster, 4? for internal partitions and 6? for external walls.
  • .Sand: Double washed M-sand for masonry and P-sand for plastering.
  • .Lintels: Provided only over openings with a bearing of 8' into the edge of the openings.
  • .UG Sump: Constructed with 6' concrete blocks, waterproof plastered, with a capacity of 8,000 liters.
  • .Entry Ramp: Not Available
  • .Protection: Protection of neighboring houses with tarpaulin.
  • .Gas Provision: Not Included
  • .Sill Level Band: Included to prevent future cracks.
  • .Damp Proof Course: Included to prevent dampness.
  • .Parapet Wall: 3' height
Electricals
  • .Switches & Switch Boards: Anchor Roma or equivalent
  • .UPS Provision: Included
  • .CCTV: Provision included, with 2 points in the front
  • .Electrical Points: Light and power points provided as per design
  • .Geyser Points: Provided in all bathrooms
  • .AC Provision: Available for all bedrooms.
  • .Conduits: High-quality, concealed in slabs and walls
  • .Fire-Proof Copper Wire: Finolex or Polycab
  • .External Electrification: Included
  • .Main DB & MCB: ABB, IndoAsian, Siemens, or equivalent make
  • .Electric Car Charging Point: One Point Provided in the parking area.
  • .Home Automation: Not Available
  • .Electrical & Plumbing budget: Rs.350/sqft on buildup area.
Plumbing
  • .CPVC & PVC Pipes: Ashirvad, Astral, or equivalent brands
  • .Overhead Tank (OHT): 1,000 liters, Sintex or equivalent
  • .Water Supply System: Internal and external
  • .External Sewage System: Includes inspection chambers and sewage outlet to site boundary
  • .Solar & Geyser Provision: Provided for all toilets
  • .Rainwater Harvesting Facility: Groundwater recharge system
  • .Plumbing: CI chamber covers provided for inspection chambers
  • .Separate Sewage & Drainage Lines: Installed
  • .Hot and Cold-Water Inlet: Not Available
Fabrications
  • .MS Gate: Up to Rs.1,200 per running foot
  • .External Staircase & Balcony Railing: MS Railing up to Rs.480 per running foot
  • .Internal Staircase: MS Railing up to Rs.650 per running foot (If applicable)
Doors & Windows
  • .Percentage of Openings: Maximum 12% of built-up area for windows and balcony doors
  • .Main Door: Teak wood frame and shutter including hardware – Rs.60,000 per door for owner house, frame thickness of 6 inches by 4 inches, shutter thickness of 38mm. For other houses, main door fitting budget will be Rs.8,000/- per door (if applicable).
  • .Internal Door: Sal wood frame and flush shutter including hardware – Rs.20,000 per door. Frame thickness of 5 inches by 3 inches, shutter thickness of 32mm.
  • .Puja Door: Not Included
  • .Polish: The Main Door and Pooja Door will be hand-polished with melamine for a smooth and durable finish.
  • .Bathroom Door: Frame and shutter including hardware – Rs.5,000 per door. Frame thickness of 4 inches by 2 inches, shutter thickness of 32mm.
  • .UPVC/Wooden Windows: 5mm clear glass with MS grills. Basic price: Rs.650 per sqft with MS grill.
Painting
  • .Internal Wall & Ceiling: 2 coat wall putty + 1 coat primer + 2 coat Tractor Emulsion – Nippon brand
  • .External Walls: 1 coat primer + ACE weatherproof paint Nippon brand
Compound Wall (If Charged)
  • .Solid Block Walls: 4 inches thick, designed to complement the elevation.
  • .Construction Details: Includes excavation, foundation, PCC, size stone masonry with DPC course above SSM.
  • .Height of Compound Wall: 5 feet from plinth level.
  • .Finish: Compound wall will be plastered and painted.
Elevation
  • .Aesthetic Design: Includes an aesthetically pleasing elevation design with budget of 0.25% on BUA.
  • .Design Options: Two elevation designs provided for the client to choose from and further refine.
Structural Warranty
  • .Construction Guarantee: 2 years
  • .Structural & Waterproofing Warranty: 8 years
Terms & Conditions
  • .Cost: Includes all applicable taxes.
  • .Floor Plan: Must be finalized within 30 days from the date of releasing the first floor plan proposal by the architect.
  • .SSM: Below the plinth is not included; if required, it will be charged based on actual costs.
  • .Sewer Line Connections: Included up to 11' feet from the building.
  • .Steel & Cement Budget: Steel brand chosen by the client, with a budget of 60,000 per MT & cement with a basic price of Rs.350 per bag. Any cost difference at the time of purchase will be charged after consulting with the client.
  • .Water, Electricity & Miscellaneous: Client must provide water and electricity for the work. Rates are based on natural earth excavation. Additional charges apply for concrete structures, stones, rock slush, or any other obstacles encountered during excavation.
  • .Site and Road Level: Cost assumes that the site and road are at the same level.
  • .Fixtures & Equipment: Does not include equipment, machinery, or fixtures such as sump pumps, solar panels, geysers, or bulbs.
  • .Approval for Power and Water: Client will bear the approval costs for power and water. Road cutting charges for connecting electricity and sewage lines are not included and will be charged additionally.
  • .Backfilling Soil: Costs for purchasing new earth or removing existing earth for excavation/backfilling purposes will be charged based on actual costs.
  • .Liaison: Assistance with BBMP/BDA/BMRDA and similar authorities will be provided by the company, with fees to be borne by the client.
Premium Package
Rs. 2999/sqft
Highly Chosen
Design & Drawings
  • .2D Floor Plan: Included
  • .3D Elevation: Included
  • .Soil test & Structural Drawings: Included
  • .Schedule of Openings: Included
  • .Furniture Layouts: Included
  • .Working Drawings: Included
  • .Electrical and Plumbing Drawings: Included
  • .Isometric Views: Included
Flooring & Tiles
  • .Living & Dining: Marble Finished Vitrified tiles of choice up to Rs.120 per sqft
  • .Kitchen, Bedrooms & Other Common Areas: Vitrified tiles of choice up to Rs.120 per sqft
  • .Staircase: Granite or tiles up to Rs.120 per sqft
  • .Balcony, Setback (if charged) & Parking: Antiskid tiles up to Rs.120 per sqft
  • .Bathroom Walls: Tiles up to Rs.120 per sqft, up to 11' height
  • .Bathroom Floor: Antiskid tiles up to Rs.120 per sqft
  • .Kitchen Dado: Tiles up to Rs.120/- per sqft, 2 feet height above countertop and full height near the chimney if required
  • .Kitchen Counter Slab: Granite choice up to Rs.120 per sqft
  • .Epoxy Grouting: Available
  • .Terrace Cooling Tiles: Not Available
Waterproofing
  • .Waterproofing shall be done in the terrace slab, all washrooms, and balconies using Fosroc / Dr Fixit Brush bond or equivalent brands.
Fittings
  • .Kitchen Sink with Accessories: ISI Mark Products up to Rs.8,000/-
  • .Kitchen Sink Faucet: ISI Mark Products up to Rs.4,000/-
  • .CP & Sanitary Fittings: ISI Mark Products up to Rs.35,000/- per toilet, for powder room up to Rs.17,500/-
  • .Utility Sink & Accessories: Make Kaff or Franke or Futura or equivalent up to Rs.6,000/-
Civil Construction
  • .Floor Height: 11'6" from finished floor level to finished floor level
  • .Steel: Kamadhenu or Buwalka – Fe550D
  • .Cement: Birla Shakthi or Dalmia
  • .Concrete: Constructed with M-20/M-25 grade concrete
  • .Aggregates: 20mm & 40mm
  • .Foundation: Assumed to be isolated footings in regular soil with a bearing capacity of 180kN/m² and above, up to a depth of 5 feet. Additional charges apply for specialized foundation designs or additional excavation depth beyond 5 feet.
  • .Plastering: Internal plastering (1:5 cement mortar), external plastering (1:5 cement mortar), and ceiling plastering (1:4 cement mortar). Internal plaster thickness 15mm, external plaster 12mm + 8mm, applied in two coats.
  • .Anti-termite Treatment: Adheres to standard procedures
  • .Chicken Mesh: Used at beam, column, and masonry wall junctions, and at electrical conduit chases.
  • .Plinth Level: Set at 1 foot 6 inches above the existing ground level.
  • .Blockwork Masonry: Standard solid concrete blocks with plaster, 4? for internal partitions and 6? for external walls, using mechanically pressed blocks.
  • .Sand: Double washed M-sand for masonry and P-sand for plastering.
  • .Lintels: Provided only over openings with a bearing of 8' into the edge of the openings.
  • .UG Sump: Constructed with 6' concrete blocks, waterproof plastered, with a capacity of 10,000 liters.
  • .Entry Ramp: Not Available
  • .Protection: Protection of neighboring houses with tarpaulin.
  • .Gas Provision: Provision for one gas line.
  • .Sill Level Band: Included to prevent future cracks.
  • .Damp Proof Course: Included to prevent dampness.
  • .Parapet Wall: 3' height
Electricals
  • .Switches & Switch Boards: Anchor Roma or equivalent
  • .UPS Provision: Included
  • .CCTV: Provision included, with 2 points in the front
  • .Electrical Points: Light and power points provided as per design
  • .Geyser Points: Provided in all bathrooms
  • .AC Provision: Available for all bedrooms.
  • .Conduits: High-quality, concealed in slabs and walls
  • .Fire-Proof Copper Wire: Finolex or Polycab
  • .External Electrification: Included
  • .Main DB & MCB: ABB, IndoAsian, Siemens, or equivalent make
  • .Electric Car Charging Point: One Point Provided in the parking area.
  • .Home Automation: Not Available
  • .Electrical & Plumbing budget: Rs.450/sqft on buildup area.
Plumbing
  • .CPVC & PVC Pipes: Ashirvad, Astral, or equivalent brands
  • .Overhead Tank (OHT): 2,000 liters, Sintex or equivalent
  • .Water Supply System: Internal and external
  • .External Sewage System: Includes inspection chambers and sewage outlet to site boundary
  • .Solar & Geyser Provision: Provided for all toilets
  • .Rainwater Harvesting Facility: Groundwater recharge system
  • .Plumbing: CI chamber covers provided for inspection chambers
  • .Separate Sewage & Drainage Lines: Installed
  • .Hot and Cold-Water Inlet: Not Available
Fabrications
  • .MS Gate: Up to Rs.1,550 per running foot
  • .External Staircase & Balcony Railing: SS Railing up to Rs.880 per running foot
  • .Internal Staircase: SS railing with glass up to Rs.1,050 per running foot (If applicable)
Doors & Windows
  • .Percentage of Openings: Maximum 18% of built-up area for windows and balcony doors
  • .Main Door: Teak wood frame and shutter including hardware – Rs.70,000 per door for owner house, frame thickness of 6 inches by 4 inches, shutter thickness of 38mm. For other houses, main door fitting budget will be Rs.10,000/- per door (if applicable).
  • .Internal Door: Sal wood frame and flush shutter including hardware – Rs.25,000 per door. Frame thickness of 5 inches by 3 inches, shutter thickness of 32mm.
  • Puja Door: Teak wood frame and wood shutter including hardware – Rs.20,000 per door (if applicable).
  • .Polish: The Main Door and Pooja Door will be hand-polished with melamine for a smooth and durable finish.
  • .Bathroom Door: Frame and shutter including hardware – Rs.8,000 per door. Frame thickness of 4 inches by 2 inches, shutter thickness of 32mm.
  • .UPVC/Wooden Windows: 5mm clear glass with MS grills. Basic price: Rs.850 per sqft for UPVC with MS grill.
Painting
  • .Internal Wall & Ceiling: 2 coats of wall putty + 1 coat of primer + 2 coats of premium emulsion, Asian brand
  • .External Walls: 1 coat of primer + ACE weatherproof paint, Asian brand
Compound Wall (If Charged)
  • .Solid Block Walls: 4 inches thick, designed to complement the elevation.
  • .Construction Details: Includes excavation, foundation, PCC, size stone masonry with DPC course above SSM.
  • .Height of Compound Wall: 5 feet from plinth level.
  • .Finish: Compound wall will be plastered and painted.
Elevation
  • .Aesthetic Design: Includes an aesthetically pleasing elevation design with a budget of 0.50% on BUA.
  • .Design Options: Three 3D elevation designs provided for the client to choose from and further refine.
Structural Warranty
  • .Construction Guarantee: 2 years
  • .Structural & Waterproofing Warranty: 8 years
Terms & Conditions
  • .Cost: Includes all applicable taxes.
  • .Floor Plan: Must be finalized within 30 days from the date of releasing the first floor plan proposal by the architect.
  • .SSM: Below the plinth is not included; if required, it will be charged based on actual costs.
  • .Sewer Line Connections: Included up to 10 feet from the building.
  • .Steel & Cement Budget: Steel & Cement price will be considered as per agreement date. Any cost difference at the time of purchase will be charged after consulting with the client.
  • .Water, Electricity & Miscellaneous: Client must provide water and electricity for the work. Rates are based on natural earth excavation. Additional charges apply for concrete structures, stones, rock slush, or any other obstacles encountered during excavation.
  • .Site and Road Level: Cost assumes that the site and road are at the same level.
  • .Fixtures & Equipment: Does not include equipment, machinery, or fixtures such as sump pumps, solar panels, geysers, or bulbs.
  • .Approval for Power and Water: Client will bear the approval costs for power and water. Road cutting charges for connecting electricity and sewage lines are not included and will be charged additionally.
  • .Backfilling Soil: Costs for purchasing new earth or removing existing earth for excavation/backfilling purposes will be charged based on actual costs.
  • .Liaison: Assistance with BBMP/BDA/BMRDA and similar authorities will be provided by the company, with fees to be borne by the client.
Ultra Luxury Package
Rs. 3299/sqft
High Value for Money
Design & Drawings
  • .2D Floor Plan: Included
  • .3D Elevation: Included
  • .Soil test & Structural Drawings: Included
  • .Schedule of Openings: Included
  • .Furniture Layouts: Included
  • .Working Drawings: Included
  • .Electrical and Plumbing Drawings: Included
  • .Isometric Views: Included
Flooring & Tiles
  • .Living & Dining: Marble Finished Vitrified Tiles of choice up to Rs.180 per sqft
  • .Kitchen, Bedrooms & Other Common Areas: Vitrified tiles of choice up to Rs.180 per sqft
  • .Staircase: Granite or tiles up to Rs.180 per sqft
  • .Balcony, Setback (if charged) & Parking: Antiskid tiles up to Rs.180 per sqft
  • .Bathroom Walls: Tiles up to Rs.180 per sqft, covering the full height
  • .Bathroom Floor: Antiskid tiles up to Rs.180 per sqft
  • .Kitchen Dado: Tiles up to Rs.180/- per sqft, 2 feet height above countertop and full height near the chimney if required
  • .Kitchen Counter Slab: Granite choice up to Rs.180 per sqft
  • .Epoxy Grouting: Applied in bathroom and balcony flooring
  • .Terrace Cooling Tiles: Tiles worth Rs.45/- per sqft
Waterproofing
  • .Waterproofing shall be done in the terrace slab, all washrooms, and balconies using Fosroc / Dr Fixit Brush bond or equivalent brands.
Fittings
  • .Kitchen Sink with Accessories: ISI Mark Product up to Rs.10,000/-
  • .Kitchen Sink Faucet: ISI Mark Product up to Rs.6,000/-
  • .CP & Sanitary Fittings: ISI Mark Products up to Rs.40,000/- per toilet, for powder room up to Rs.20,000/-
  • .Utility Sink & Accessories: Choice up to Rs.10,000/-
Civil Construction
  • .Floor Height: 11’6"? from finished floor level to finished floor level
  • .Steel: JSW Fe550D
  • .Cement: ACC or Birla Super
  • .Concrete: Constructed with M-20/M-25 grade concrete
  • .Aggregates: 20mm & 40mm
  • .Foundation: Assumed to be isolated footings in regular soil with a bearing capacity of 180kN/m² and above, up to a depth of 5 feet. Additional charges apply for specialized foundation designs or additional excavation depth beyond 5 feet.
  • .Plastering: Internal plastering (1:5 cement mortar), external plastering (1:5 cement mortar), and ceiling plastering (1:4 cement mortar). Internal plaster thickness 15mm, external plaster 12mm + 8mm, applied in two coats.
  • .Anti-termite Treatment: Adheres to standard procedures
  • .Chicken Mesh: Used at beam, column, and masonry wall junctions, and at electrical conduit chases.
  • .Plinth Level: Set at 1 foot 6 inches above the existing ground level.
  • .Blockwork Masonry: Standard solid concrete blocks with plaster, 4' for internal partitions and 6' for external walls, using mechanically pressed blocks (Alpha or equivalent brands).
  • .Sand: Double washed M-sand for masonry and P-sand for plastering.
  • .Lintels: Provided only over openings with a bearing of 6? into the edge of the openings.
  • .UG Sump: Constructed with 8? concrete blocks, waterproof plastered, with a capacity of 12,000 liters.
  • .Entry Ramp: Included based on the site conditions.
  • .Protection: Protection of neighboring houses with tarpaulin.
  • .Gas Provision: Provision for one gas line.
  • .Sill Level Band: Included to prevent future cracks.
  • .Damp Proof Course: Included to prevent dampness.
  • .Parapet Wall: 3' height
Electricals
  • .Switches & Switch Boards: Havells or Legrand
  • .UPS Provision: Included
  • .CCTV: Provision included, with 2 points in the front
  • .Electrical Points: Light and power points provided as per design
  • .Geyser Points: Provided in all bathrooms
  • .AC Provision: Available for all bedrooms and main living area
  • .Conduits: High-quality, concealed in slabs and walls
  • .Fire-Proof Copper Wire: Finolex or Polycab
  • .External Electrification: Included
  • .Main DB & MCB: ABB, IndoAsian, Siemens, or equivalent make
  • .Electric Car Charging Point: One Point Provided in the parking area.
  • .Home Automation: Included
  • .Electrical & Plumbing budget: Rs.550/sqft on buildup area.
Plumbing
  • .CPVC & PVC Pipes: Ashirvad, Astral, or equivalent brands
  • .Overhead Tank (OHT): 2,000 liters, Sintex or equivalent
  • .Water Supply System: Internal and external
  • .External Sewage System: Includes inspection chambers and sewage outlet to site boundary
  • .Solar & Geyser Provision: Provided for all toilets
  • .Rainwater Harvesting Facility: Groundwater recharge system
  • .Plumbing: GI chamber covers provided for inspection chambers
  • .Separate Sewage & Drainage Lines: Installed
  • .Hot and Cold-Water Inlet: Will be installed for kitchen sink
Fabrications
  • .MS Gate: Up to Rs.1,950 per running foot
  • .External Staircase & Balcony Railing: SS Railing up to Rs.880 per running foot
  • .Internal Staircase: SS railing with glass up to Rs.1,550 per running foot (If applicable)
Doors & Windows
  • .Percentage of Openings: Maximum 20% of built-up area for windows and balcony doors
  • .Main Door: Teak wood frame and shutter including hardware – Rs.85,000 per door for owner house. Frame thickness of 6 inches by 4 inches, shutter thickness of 38mm. For other houses, main door fitting budget will be Rs.13,000/- per door (if applicable).
  • .Internal Door: Sal wood frame and flush shutter including hardware – Rs.25,000 per door. Frame thickness of 5 inches by 3 inches, shutter thickness of 32mm.
  • .Puja Door: Teak wood frame and wood shutter including hardware – Rs.30,000 per door (if applicable).
  • .Polish: The Main Door and Pooja Door will be hand-polished with melamine for a smooth and durable finish.
  • .Bathroom Door: Frame and shutter including hardware – Rs.10,500 per door. Frame thickness of 4 inches by 2 inches, shutter thickness of 32mm.
  • .UPVC/Wooden Windows: 5mm clear glass with MS grills. Basic price: Rs.1200 per sqft for UPVC with MS grill.
Painting
  • .Internal Wall & Ceiling: 2 coats of wall putty + 1 coat of primer + 2 coats of Royal emulsion, Asian brand
  • .External Walls: 1 coat of primer + ACE weatherproof paint, Asian brand
Compound Wall (If Charged)
  • .Solid Block Walls: 4 inches thick, designed to complement the elevation.
  • .Construction Details: Includes excavation, foundation, PCC, size stone masonry with DPC course above SSM.
  • .Height of Compound Wall: 5 feet from plinth level.
  • .Finish: Compound wall will be plastered and painted.
Elevation
  • .Aesthetic Design: Includes an aesthetically pleasing elevation design with a budget of 1.0% on BUA.
  • .Design Options: Three 3D elevation designs provided for the client to choose from and further refine.
Structural Warranty
  • .Construction Guarantee: 2 years
  • .Structural & Waterproofing Warranty: 8 years
Terms & Conditions
  • .Cost: Includes all applicable taxes.
  • .Floor Plan: Must be finalized within 30 days from the date of releasing the first floor plan proposal by the architect.
  • .SSM: Below the plinth is not included; if required, it will be charged based on actual costs.
  • .Sewer Line Connections: Included up to 10 feet from the building.
  • .Steel & Cement price will be considered as per agreement date, if there is a major fluctuation exceeding 5% of the average market price at the time of purchasing, the difference shall be charged in consultation with the client.
  • .Water, Electricity & Miscellaneous: Client must provide water and electricity for the work. Rates are based on natural earth excavation. Additional charges apply for concrete structures, stones, rock slush, or any other obstacles encountered during excavation.
  • .Site and Road Level: Cost assumes that the site and road are at the same level.
  • .Fixtures & Equipment: Does not include equipment, machinery, or fixtures such as sump pumps, solar panels, geysers, or bulbs.
  • .Approval for Power and Water: Client will bear the approval costs for power and water. Road cutting charges for connecting electricity and sewage lines are not included and will be charged additionally.
  • .Backfilling Soil: Costs for purchasing new earth or removing existing earth for excavation/backfilling purposes will be charged based on actual costs.
  • .Liaison: Assistance with BBMP/BDA/BMRDA and similar authorities will be provided by the company, with fees to be borne by the client.

Design Packages


Select Your Architectural Design Package
Basic
Rs.45 per sqft
Concept Design


Standard
Rs.95 per sqft
Concept Design + Working Drawings

Premium
Rs.140 per sqft
Concept Design + Working Drawings + Interior

Ultra Premium
Rs.240 per sqft
Concept Design + Working Drawings + Interior + Material Selection
SCHEME DRAWING : ALL FLOORS (2D)
FURNITURE LAYOUT : ALL FLOORS (2D)
ELEVATION DESIGN (3D)
ELECTRICAL DRAWINGS : ALL FLOORS (2D)
PLUMBING DRAWING : ALL FLOORS (2D)
WORKING DRAWING : ALL FLOORS (2D)
SOIL TESTING REPORT
STRUCTURAL DRAWINGS
SITE ASSESSMENT & SITE PLAN
ELEVATION DETAIL DRAWING (2D)
HALF LAYOUT : ALL FLOORS (3D)
INTERIOR VIEWS : ALL ROOMS (3D)
INTERIOR DETAILING : ALL ROOMS (2D)
MATERIAL & BRAND SELECTION
LANDSCAPING ARCHITECTURE DESIGNS
TOPOGRAPHICAL SURVEY
APPROVAL DRAWING
OFFICE VISITSMax 4Max 8
CONSTRUCTION QUOTATION
INTERIOR QUOTATION
DELIVERY TIME6 Working Days20 Working Days30 Working Days45 Working Days

Note:

  • Site Supervision & Construction Support not included
  • Minimum Built-up area should be 1800 sqft
  • Initial site Assessment visit will be done only for Sites in Chennai, Bangalore, Hyderabad, Pondicherry and Coimbatore
  • Dedicated web and app access for 4 years
  • 2-Sets of A3 Printed hard copies will be provided



Construction Calculator

Total Cost: Rs.0/-
1.
